| Model |
6K |
6KS |
10K |
10KS |
| Rating |
6KVA/4.8kW |
10KVA/8KW |
| Input |
Input system |
Single phase & earth ground |
| Voltage range |
(120±5)VAC ~ (274±5)VAC |
| Power factor |
≥0.99 |
| Voltage range of bypass |
(60±5)VAC~(300±5)VAC (default: 80VAC~ 264VAC Could be adjusted by software) |
| Output |
Output system |
Single phase & earth ground |
| Rated voltage |
220VAC |
| Power factor |
0.8 |
| Voltage precision |
±1% |
| Output frequency |
Normal mode |
1. The output frequency synchronizes with the input frequency when the input frequency is in the range of 46 Hz ~ 54 Hz. |
| 2. The output frequency is 50Hz when the input frequency is not in the range of 46 Hz ~ 54 Hz. |
| Battery mode |
3. Can be set as 60Hz. |
| Inverter overload capacity (Utility power, 25 °C) |
105% ± 5% < Load ≤ 125% ± 5% 60s transfer to bypass |
| 125% ± 5% < Load ≤ 135% ± 5% 30s transfer to bypass |
| Load > 135% ± 5%, 100ms transfer to bypass |
| Transfer time |
0ms (Normal mode←→Battery mode) |
| <4ms (Normal mode←→Bypass mode) |
| Crest factor |
3:01 |
| Battery |
Batteries voltage |
144VDC |
|
|
|
| Batteries quantity |
16 |
None |
16 |
None |
| Battery Type |
Sealed maintenance-free lead -acid battery of battery voltage 12V/7AH |
| Backup Time (25 °C) |
Full load ≥ 5min (Standard) |
| Charge current |
1A |
5.5A |
1A |
5.5A |
| Dimensions (L*W*H)mm |
560x260x717 |
425x190x328 |
560x260x717 |
533x260x501 |
| Weight (kg) |
61.5 |
12.5 |
62 |
21 |
